Power Quality

The Power Master 4000 is a phase A powered, 3 phase power quality analyser with harmonics to the 50th, flicker and automatic reports.

About The PM4000

Full Power Quality Survey. No Fuss.

• Pre-loaded PQ survey configuration means hook it up and start recording. No thresholds, no fuss, all the results you need.

Nuisance Tripping? Record without thresholds.

• No thresholds need to be set for detailed event or waveform capture. Is it the supply or your installation causing the trip?

Safe, Long Term Recording.

• A 600V Cat IV (1000V Cat III) analyser powered off phase A or 12Vdc charger. Remote comms available via our mobile app. PMGateway.
• With FIFO mode and automatic download to USB, carry on recording until a specific event occurs, then collect your data.

Solve Customer Complaints Quickly.

• Advise customers competently on voltage surges, dips, flicker or harmonics problems comparing any data streams in the Outram Research Ltd Software, Pronto for Windows, e.g. RMS voltage and Instantaneous Flicker, on the same graph.
• Minimise customer disruption by finding problems quickly using Adaptive StoreTM. Record single cycle detail during events with no thresholds set.
• Comprehensive, quick, consistent reports using graph and table templates in Pronto for Windows.

Preventative Maintenance

• Monitor your power quality over time to detect any problems before they cause equipment failure or costly down time.

Check Pre and Post Equipment Installation

• Benchmark before and check after the installation of new equipment to ensure quality of service has been maintained.

Monitor Your Motor Performance.

• Are your machines deteriorating due to poor power quality? Observe the supply to your motors, checking for unbalance and harmonics in real time.

‍

Power quality, harmonics, flicker and waveforms monitor.

The Power Master 7000 is a user-friendly, comprehensive, compact and cost-effective power quality monitoring and trouble-shooting unit.

Highly commended in the Electrical Industry Awards 2009, the Power Master 7000 is a user-friendly, comprehensive, compact and cost-effective power quality monitoring and trouble-shooting unit.

It offers virtually everything needed to monitor and record power for surveys and audits. It includes 4 voltage input channels capable for measuring 0 to 600 Vac and 4 current input channels for use with voltage output current clamps, or Rogowski Coil sensors supplied. Twelve pre-stored connection configurations are set for 3 phase, 2 phase and single phase measurements. Users can also configure their own set-up and math calculation requirements and save them to non-volatile memory.

The PM7000 complements the Adaptive Store function with intelligent Waveform Capture. This real-time, auto-ranking mechanism is able to track and rank multiple categories of transient and other problem event types. It discards smaller events when larger ones occur, which means the best, most revealing events are captured without any prior knowledge of what might happen – and without wasting store, and without any re-arming time. This makes the whole waveform capture process sensitive/generous/sensible, abstemious and efficient instead of profligate – so data transfer, storage and search times are minimised. Like the benefits of Adaptive Store, these are also achieved without setting any thresholds! The PM7000 supports EREC G5/5 recommendations.

‍

Three Phase power quality, harmonics and flicker monitor

The PM3000HF Power Logger is the best value 3 phase power quality & harmonic logger on the market today.

The PM3000HF Power Logger is the best value 3 phase power quality & harmonic logger on the market today.

It measures almost every aspect of the electricity you’re supplying or receiving, so is a must for utility, electricity and power supply companies as well as large industrial consumers, from heavy machinery plants to hospitals and supermarkets.

The PM3000HF now comes with 3 memory options: 8MB (Standard), 16MB, and 32MB. You will now be able to record down to single cycle detail for up to 2 months at a time.

DC Measurement Upgrade Available

Contact us now to see if your existing PM3000HF can be fitted with a DC Measurement or Extra Memory Upgrade.

‍

Single phase power quality, harmonics and flicker monitor.

The PM1000 is ideal for responding to residential voltage complaints and power consumption problems

The PowerMaster 1000 Single Phase Logger is a 3-channel data logging system built into an easy to carry housing. It is ideal for responding to residential voltage complaints and power consumption problems. It is particularly useful for troubleshooting.

It monitors line to neutral and neutral to earth voltages and one current signal that accepts rogowski coils or traditional current clamps. Flicker Measurements are made to IEC 61000-4-15.

Data is retrieved via a USB-C or Bluetooth serial port. Date and time, recording length, recording mode, sample rate, math channel usage and more can be configured from a laptop or personal computer via the serial port.

Simply plug the PM1000 into the mains or attach to the power to be measured and it will start to record automatically. You can configure it in advance and store ‘set ups’ on the computer or on the logger.

‍

The Megger MPQ1000 handheld power quality analyser has features which make it ideal for troubleshooting, compliance testing and energy audits.  Auto CT identification eliminates potential errors due to wrong CT range settings. The analyser will automatically identify the CT and verify it is connected correctly. This means you can be confident you will have the correct data.

But the hardware is not all it’s about – behind the sturdy exterior is an intelligence that is focused on smart testing, with industry-leading software that enables you to minimize errors while testing, and quickly and easily analyse your results. For example, you can create your own company standard templates that can be stored and compared, as well as check your results against compliance standards.  This saves time, effort and costs, making your entire testing process more efficient.

The software automatically creates custom configurations based on the issue you are troubleshooting, whether it be equipment tripping out, transformer or motor issues, EN50160 analysis or general PQ analysis. This ensures the analyser will capture the power quality phenomenon that causes those problems. You do not have to be a PQ expert to carry out a comprehensive analysis.

‍

The EC-1V is used by power distribution companies, facilities management, voltage/energy optimisation companies, electrical or site services and maintenance engineers to monitor voltage variations on site helping them to diagnose any voltage related issues, or to gather data perhaps to make representations to their power supplier.

Voltage optimisation companies also use the product to monitor voltage levels pre and post optimisation. Many power distribution companies use the product to highlight real voltage problems for further investigation with more sophisticated recorders.

Kit includes data logger, voltage lead, USB lead, Electrosoft software and a carry case. Please consider if you additionally require a convertor for use with your logger / computer, refer to our related products below.

The advantage of the Electrocorder products over most others is that our data loggers constantly sample information (recording the Min, Max and Average) over the set period, many other products only take 'snap shots' of what is going on and can miss 99.9% of the data that is critical to your analysis.

The EC-1V is a single-phase voltage data logger.  Setup the Logger using the Electrosoft software, then simply plug into a mains socket.

This logger can be installed by anyone when fitted with a plug!  Once you're set up, just turn on the voltage supply/socket and it'll start logging. The onboard indicator will flash Green when logging.

When the logger's finished recording (or you've captured enough data!) just disconnect from supply, hook it up to your PC and download the information.  Electrosoft will let you view the data immediately on-screen and save or export for later analysis.

‍

Monitor charging circuits, PV (photovoltaic) cell, DC motor and many other application.

Records voltage up to 300Vdc & loads up to 1kAdc,model dependent

Data stored in non-volatile memory

Memory capacity of 32,000 (True RMS) values per channel(10bit), up to 300 days continuous recording

Selectable averaging period from 1 second to 60 minutes

‍

Arguably one of the most popular and best-priced such loggers on the Australasian market!

Packaged in a robust IP65 case, the EC7VAR logs 3 Phase Voltage, Current, Power Factor, and Energy.  An ideal and comprehensive means to survey a customer’s energy consumption and then to display the results (via acclaimed yet simple software) in a clear graph that will appeal to any manager or Board.  Popular with retail stores, factories, and larger installations where the power bill really matters.

Used by electrical contractors, power distribution companies, facilities management, electrical or site-services and maintenance engineers to monitor power (kW)/energy (kWh) usage, check voltage and current variations helping them to diagnose any related issues, or to gather data perhaps to make representations to their power supplier. Extensively used for Photovoltaic or UPS sizing & monitoring, and standby generator sizing and monitoring. As the product records both voltage and current, users can determine if low voltage is related to high current demands on site, or if the low voltage is being supplied to the site. The highly flexible Rogowski Coils rated 1000amp each (optional 3000 A ones available at additional cost) fit around cables of 140mm diameter cables. Note, the Rogowski Coils break open at the black joint, allowing them to be placed around the cables without having to break the main circuit.

‍

Enables 3 phase loading and/or balancing problems to be high-lighted quickly as well as assessment of energy usage over time

Data stored in non-volatile memory

Memory capacity of 32,000 (True RMS) values per channel(10bit), up to 300 days continuous recording

Selectable averaging period from 1 second to 60 minute

‍

Enables 3 phase loading and/or balancing problems to be high-lighted quickly as well as assessment of energy usage over time

Data stored in non-volatile memory

Memory capacity of 32,000 (True RMS) values per channel(10bit), up to 300 days continuous recording

Selectable averaging period from 1 second to 60 minutes

‍

The SR-1R data logger is used by installers, householders, renewable energy companies to assess proposed locations for a PV (photovoltaic) and Solar Thermal installations. It can record solar irradiation up to 1500W/m2 (watts per square metre), allowing you to estimate the amount of solar energy a given site will have. The logger will record up to 300 days using the included PSU (power supply unit), data can be downloaded to the free software, Electrosoft and analysed.

Solar Irradiance is recorded to 1500W/m2 with the EC-SP-110 Pyranometer.

The advantage of the Electrocorder products over most others is that our data loggers constantly sample information (recording the Min, Max and Average) over the set period, many other products only take 'snap shots' of what is going on and can miss 99.9% of the data that is critical to your analysis.

Kit includes data logger, pyranometer, RS232 serial lead, 12Vdc PSU, Electrosoft software and a carry case.

‍

The PV-3 data logger is used by installers, householders, renewable energy companies  to check PV (photo voltaic) installations. It can record solar irradiation up to 1,500W/m2 (watts per square metre), DC Voltage and DC Current produced by the panel, allowing you to assess the performance of a solar energy installation. The logger will record up to 300 days using the included PSU (power supply unit), data can be downloaded to the free software, Electrosoft and analysed.

The advantage of the Electrocorder products over most others is that our data loggers constantly sample information (recording the Min, Max and Average) over the set period, many other products only take 'snap shots' of what is going on and can miss 99.9% of the data that is critical to your analysis.

Kit includes data logger, fused voltage input leads, DC current probe, pyranometer, USB lead, 12Vdc PSU, Electrosoft software and a carry case.

‍
